Karcher Puzzi 10/1 Spray Extraction Cleaner


Spray-extraction cleaner with revolutionary flexible suction tool, providing new levels of convenience and ease of use for cleaning carpets and upholstery.


The powerful Puzzi 10/1 spray-extraction cleaner provides new levels of convenience and ease of use, thanks to a host of design features all intended to make carpet and upholstery cleaning more productive and therefore quicker and at lower cost. Using the proven spray-extraction method, the Puzzi 10/1 deep cleans carpets and leaves only minimal residual moisture. This means that carpets and upholstery are left almost completely dry, reducing the risk of resoiling and enabling cleaned areas to be used again very quickly. Kärcher’s revolutionary flexible suction tool features a rotating plastic lip which ensures optimum contact is made regardless of the angle of the floor tool, dramatically improving ease of use and cleaning results.

Features and Benefits

  • Improved cleaning performance
  • Storage compartment for cleaning agent tablets
  • Versatility of use


Technical data

  • Max. area performance (m²/h/m²/h) – 20/25
  • Air flow (l/s) – 54
  • Vacuum (mbar) – 220/22
  • Spray rate (l/min) – 1
  • Spray pressure/ram pressure (bar) – 1
  • Fresh / waste water tank (l) -10-9
  • Power rating fan (W) – 1250
  • Power rating, pump (W) – 40
  • Voltage (V) – 230/240
  • Weight (kg) – 10.7
  • Dimensions (L x W x H) (mm) – 705 x 320 x 435


  • Spray hose with integral water feed, 2.5 m
  • Integral accessory holder for hand tool
  • Upholstery nozzle
  • Additional handle
  • Cable hook
  • Narrow floor nozzle with flexible suction lip
  • Hand tool
